ETSP-VD series are designed for removing water from the surface or interior of certain products or substrates or removal of moisture from water-based coatings and adhesives. ETSP-VD series are designed and built to your specific requirements for part size, production rate and thermal characteristics.
- Tight seal at a vacuum level by equipped door gasket and a push button latch
- Block type heaters heat the chamber evenly and good transmission by anodized aluminum plate shelve
- Heat tempered full view window permits continuous monitoring
- Programmable type temerature controller and programmable type vacuum controller (option)
- Excellent space efficiency and user friendly all in one type operating panel
- Microprocess PID control / Auto-tuning / Calibration
- Over temperature limiter / Door opening alarm
- Digital LED display (1 ℃ resolution) with touch-sensitive keypads
- RS-232/RS485 data interface
| Temperature range | Ambient +5 ℃ ~ +250 ℃ |
|---|---|
| Temperature fluctuation | Less than ± 0.5 ℃ (vacuum), Less than ± 1.0 ℃ (atmospheric) |
| Temperature uniformity | Less than ± 2.0 ℃ at 100 ℃ |
| Heat up time to 200 ℃ | Within 55 minutes under vacuum with no load |
| Max. final vacuum | 100Pa (1mbar)(more higher vacuum range is option) |
| Pull down rate from atmospheric pressure to 1mbar | Within 18 minutes |
| Recovery time | Winhin 11 minutes |
| Input power requirements | 230V/380V, 50Hz/60Hz, 1Ph/3Ph (Changeable according to customer specification) |
| Model | Internal dimensions | External dimensions | Useful capacity |
|---|---|---|---|
| ETSP-VD 27 | 300x300x300 (WxDxH) mm | 680x450x495 (WxDxH) mm | 27 liters |
| ETSP-VD 64 | 400x400x400 (WxDxH) mm | 780x550x595 (WxDxH) mm | 65 liters |
| ETSP-VD 130 | 500x530x490 (WxDxH) mm | 950x780x800 (WxDxH) mm | 130 liters |
| ETSP-VD 512 | 800x800x800 (WxDxH) mm | 1060x960x1450 (WxDxH) mm | 512 liters |
